SplashKit LED XL RGrBW square /DMX/02 INT
SKU: 84839
View other products in the family
Feature Details
Square variant for the suspended as well as the incorporated construction, load-bearing capacity up to 20 kN
Homogeneous illumination of the fountain by uniformly calibrated LEDs
Almost unlimited color spectrum of dark royal blue, green, red and neutral white 4,000 K white
Easy installation via the patented OASE ProNect connector (0.5 m hybrid cable included with the LED)
Central opening for connecting the orb nozzle, drain openings for flowing water
Dmx/rdm-capable
simple programming and the possibility to retrieve status information about the operation
Temperature-controlled, high-quality brand LEDs with a lifespan of up to 100,000 hours*
Perfectly combinable with all SplashKit components
Specifications
Specification breakdown
- Certificate
- Dekra US + C
- Number of DMX channels
- 5
- Units
- Luminous flux with all on
- 2511
- lm
- Luminous flux red
- 720
- lm
- Luminous flux green
- 1380
- lm
- Royal blue luminous flux
- 411
- lm
- Luminous flux withe
- 391
- lm
- Colour temperature LED white
- 4000 (± 200)
- K
- Beam angle
- 11 Degrees (± 2)
- Stroboscope effect
- 0-25 Hz
- Weighted energy consumption
- 77
- kWh/1000h
- Rated voltage
- 24 V / DC
- Power consumption
- 70
- W
- Rated current
- 3.1
- A
- Dim frequency
- 2800
- Hz
- Power connection type
- Hybrid socket
- Power cable length
- 0.50
- m
- Protection class
- IP68; 4 m
- Dimensions (Ø × H)
- 330 × 63
- mm
- Material
- Stainless steel 1.4571 (AISI 316Ti)
- Net weight
- 6
- kg
Downloads
- DOK_PRD_GA_77723-GA-LED-XL-Ring-steuerbar-01.pdf
- DOK_PRD_DB_84839-SplashKit-LED-RGrBW-square.pdf
- DOK_PRD_LV_84839-SplashKit-LED-XL-RGrBW-square-DMX-02.pdf
- ZEI_PRD_AC_84839-SplashKit-LED-XL-RGrBW-square-DMX-02.dxf
- ZEI_PRD_3D_84839-SplashKit-LED-XL-RGrBW-square-DMX-02.dwg
