The ProfiFloor LED S RGB Spot /DMX/02 is the powerful, robust RGB-LED light for wall mounting or ground installation and a beam angle of 25°, 277 lumens.
The coloured LED light comes with high quality, robust stainless steel housing for fresh water, pool water and sea water. The flat surface prevents deposition of dirt. These LED lights have a temperature regulation so that wet and dry installation is possible. The temperature controlled high-class brand LED has a lifetime up to 100,000 hours.* The brightness of the basic colors of the LED RGB lights are measuredindividually. The Underwater LED Driver Compact /DMX/02 ensures equal brightness for all lights in the system, thereby creating a homogeneous colour combination.
The coloured LED light comes with high quality, robust stainless steel housing for fresh water, pool water and sea water. The flat surface prevents deposition of dirt. These LED lights have a temperature regulation so that wet and dry installation is possible. The temperature controlled high-class brand LED has a lifetime up to 100,000 hours.* The brightness of the basic colors of the LED RGB lights are measuredindividually. The Underwater LED Driver Compact /DMX/02 ensures equal brightness for all lights in the system, thereby creating a homogeneous colour combination.
Jellemzők részletei
Waterproof according to IP68 up to 4 m water depth
1 m cable length with patented waterproof OASE ProNect connector
Powerful, robust RGB LED spotlight for wet and dry installation with homogeneous coloured illumination by uniformly calibrated LEDs
High-quality, robust stainless steel housing for wall or floor mounting, drive-over resistant up to max. 1.5 t
Temperature-controlled, high-quality brand LEDs with a lifespan of up to 100,000 hours*
Level surface by stepped glass prevents dirt deposits
DMX/RDM-capable with the Underwater LED-Driver Compact/DMX/02, dimmable, perfect for strobe effects
Galvanic isolation between DMX and 24 V DC
Slide 1 of 2
1 of 2
Slide 1 of 6
1 of 6
Műszaki adatok
Specification breakdown
- Tanúsítvány
- Dekra US + C
- DMX csatornák száma
- 5
- DB
- DMX 1. csatorna
- red
- DMX 2. csatorna
- green
- DMX 3. csatorna
- blue
- DMX csatorna 4
- strobe
- DMX 5-ös csatorna
- dimmable
- Fényáram bekapcsolt állapotban
- 277
- lm
- Vörös fényáram
- 83
- lm
- Zöld fényáram
- 148
- lm
- Kék fényáram
- 46
- lm
- Fényszórási szög
- 25 ° (± 2)
- Stroboszkóp hatás
- 0-25 Hz
- Súlyozott energiafogyasztás
- 11
- kWh/1000h
- névleges feszültség
- 24 V / DC
- teljesítményfelvétel
- 10
- W
- névleges áram
- 0,44
- A
- Fényerő-szabályozási frekvencia
- 2800
- Hz
- Villamosenergia-csatlakozás típusa
- Hibrid dugasz
- kábelhossz
- 1,00
- m
- védelmi osztály
- IP68; 4 m
- Méretek (Ø × m)
- 109 × 50
- mm
- Anyag
- Prémium acél 1.4404 (AISI 316L)
- Nettó súly
- 0.7
- kg
Letöltések
- 3D drawing
- 2D drawing
- 2D drawing
- Eulumdat-files
- Replacement list
- Product data sheet
- Bill of quantity
- Product instructions
