BioTec ScreenMatic² 18000

Name: BioTec ScreenMatic² 18000
SKU: 42975
Availability: InStock

SKU: 42975

WARNING: This product can expose you to chemicals including Lead that is known to the State of California to cause Cancer. For more information go to www.p65warnings.ca.gov

Key Features

Clear and healthy pond water with minimum maintenance requirements
Particularly long service life thanks to automatic coarse debris extraction before it enters into the filter
Continuous belt filter at an affordable price

Clear water guarantee

Find out more

How To Get It

Free shipping for orders over $100

Standard delivery orders are shipped in 1-3 days

Visit an Oase dealer

User our dealer locator to find your closest retailer

Find a dealer

Thanks to clever improvements, the high-performance BioTec ScreenMatic filter has experienced a unique leap in quality compared to the ScreenMatic². The double sealing of the motor extends its service life many times over. The adjustable automatic cleaning system produces a significantly more efficient separation result. A water distributor without bottlenecks prevents blockages. The new shape increases the collection volume and makes it easier to remove the dirt basket. There are also improvements in the filter technology: innovative dirt barriers prevent the filter from being washed out. Raising the overall water level allows the filter capacity to be fully utilised. The many new features also include all-round improved handling, a more robust design and a storm-proof lid attachment for the 40,000 and 60,000 models.

Product video

Accessories you will need

Bitron C 55

$0.00

SKU: 56936

SFC-Switch<br />With AquaMax Eco Premium 5000-21000: When the SFC function is activated, the pump automatically optimizes (temperature-dependent) water volume and head and reduces them by up to 50%.

AquaMax Eco Premium 4500

$0.00

SKU: 87583

AquaMax Eco Classic 3600

$0.00

SKU: 57623

AquaMax Eco Premium 3000 - 12V

$0.00

SKU: 88675

Accessories you will need

Bitron C 55

$0.00

SKU: 56936

AquaMax Eco Premium 4500

$0.00

SKU: 87583

AquaMax Eco Classic 3600

$0.00

SKU: 57623

AquaMax Eco Premium 3000 - 12V

$0.00

SKU: 88675

Accessories you will need

Characteristics

Guaranteed
Includes OASE clear water guarantee
Low maintenance
Coarse dirt is removed before it enters the filter
Self-cleaning
The filter belt is automatically driven; adjustable automatic cleaning system, which controls the belt run based on the degree of contamination, including LED function check
Convenient
Filter sponges can be cleaned directly in the filter
Clean and tidy
Bottom drain with slide to remove dirt from the filter system
Smart combo
Different filter media for optimal development of filter biology
Extra for thread algae
Use of PhosLess filter cartridges for reducing thread algae (optional accessory)
Suitable pumps
Optimally matched to OASE AquaMax Eco filter pumps
Good partners
Direct connection option for UVC Bitron C and Eco clarifiers
DOESN'T CLOG: Uniform water distribution on the filter belt
Practical
Large-volume dirt basket with easy cleaning

High-quality filter foam<br />Different types of filter foam with various pore sizes ensure optimal mechanical and biological filtration<br />

High-quality filter foam
Different types of filter foam with various pore sizes ensure optimal mechanical and biological filtration

Integrated debris basket<br />Filtered debris can be conveniently removed and cleared from the filter system<br />

Integrated debris basket
Filtered debris can be conveniently removed and cleared from the filter system

Intelligent function checks<br />Sensors detect the pollutant level and activate the belt run automatically. An LED display shows required cleaning measures.

Intelligent function checks
Sensors detect the pollutant level and activate the belt run automatically. An LED display shows required cleaning measures.

Optimised belt<br />The cleaning belt can be easily folded to make it easy to clean the filter foam<br />

Optimised belt
The cleaning belt can be easily folded to make it easy to clean the filter foam

Schematic diagram<br />UVC clarifier in combination with OASE BioTec ScreenMatic² flow-through filter.

Schematic diagram
UVC clarifier in combination with OASE BioTec ScreenMatic² flow-through filter.

1 of 5

Downloads

DOK_PRD_GA_93093-GA-BioTec-ScreenMatic-US-2023-01.pdf

Spare Parts (60 Items)

Pos.	Product	SKU	Quantity
1 Filter Cover with Clips for BioTec ScreenMatic² 18000 / 24000 45320 1 2 Housing Clip for AquaMax Premium & BioTec ScreenMatic 30983 1
1	Filter Cover with Clips for BioTec ScreenMatic² 18000 / 24000	45320	1
2	Housing Clip for AquaMax Premium & BioTec ScreenMatic	30983	1
3	Debris Basket for BioTec ScreenMatic² 18000 / 24000 / 32000 / 38000 / 39000	42346	1
4	Scrub Brush for BioTec ScreenMatic2 18000 / 24000 / 38000 / 39000	42449	1
5	Screen Holder for BioTec ScreenMatic² 18000	42344	1
6	25507	25507	1
7	Partition Wall for BioTec ScreenMatic² 18000	42341	1
8	84923	84923	1
9	34830	34830	2
10	Sludge Drain Pull Rod for BioTec ScreenMatic² 18000 / 24000	25624	1
11	Filter Box with Holes for BioTec ScreenMatic2 18000	43106	1
12	Screen Holder Arms for BioTec ScreenMatic² 18000 / 24000 / 32000 / 39000	44181	1
13	Cleaning Tool for BioTec 12 / 36 / 18000 / 32000	34734	1
14	Power Supply for BioTec ScreenMatic² 18000 / 24000 / 38000 & Garden Cloud Controller	45291	1
15	Drain Plug for BioTec ScreenMatic² 18000 / 24000	44343	1
16	Screen Assembly for BioTec ScreenMatic² 18000 / 24000	42383	1
17	Small Parts Pack for BioTec ScreenMatic² 18000 / 24000 / 32000 / 39000	44178	1
18	Controller for BioTec ScreenMatic2 18000 / 240000	44184	1
19	Fabric Screen for BioTec 18 & BioTec ScreenMatic² 18000 / 24000	42325	1
20	Screen ScraperAssembly with Brush for BioTec ScreenMatic² 18000 / 24000 / 32000 / 39000	44177	1
21	Screen Motor for BioTec ScreenMatic2 18000 / 24000 / 38000 / 39000	44183	1
22	Connection Kit for BioTec ScreenMatic² 18000 / 24000 / 32000 / 38000/ 39000	48674	1
23	43749	43749	1
24	Flat Gasket for BioTec 12-36 & BioTec ScreenMatic² 18000 / 24000 / 32000 / 38000 / 39000	19506	1
25	Flow Distributor for BioTec ScreenMatic² 18000 / 24000	44337	1
26	O-Ring for BioTec 12-36 & BioTec ScreenMatic² 18000 / 24000 / 32000 / 38000 / 39000	25691	1
27	42949	42949	1
28	44179	44179	1
29	25000	25000	8
31	Drain Valve Assembly for BioTec 12-18 & BioTec ScreenMatic2 18000 / 24000 / 38000	44182	1
32	Drain Valve Gasket for BioTec 12 / 18 & BioTec ScreenMatic² 18000 / 24000	34859	1
33	Foam Holder Cover Plate for BioTec 18-36 & BioTec ScreenMatic² 18000 / 24000 / 32000 / 38000 / 39000	34670	8
34	42896	42896	1
35	Foam Holder for BioTec 18-36 & BioTec ScreenMatic² 18000 / 32000 / 38000 / 39000	34733	8
37	42894	42894	1
38	Brush Holder for BioTec ScreenMatic2 18000 / 24000 / 38000 / 39000	44308	1
39	Mud Flap Cap for BioTec ScreenMatic² 18000 / 24000 / 32000 / 38000 / 39000	42450	1
50	45325	45325	1
