Adapter G 30 / NPT 30 Silver INT
SKU: 51029
View other products in the family
Belangrijkste kenmerken
- Easy installation
Kenmerkdetails
Adapter for connecting G and NPT threads
Available for connections of G 1/NPT 1", G 1 ½/NPT 1 ½", G 2/NPT 2" and G 3/NPT 3"
Easy to assemble
Suitable for use in fresh and pool water
Slide 1 of 2
1 of 2
Specificaties
Specification breakdown
- A
- 78
- mm
- B
- 37
- mm
- C
- 20
- mm
- SW
- 90
- mm
- G
- 3
- in.
- Material
- Brass, nickel-plated
- Net weight
- 0.98
- kg
Downloads
- ZEI_PRD_AC_51029-AdapterG30-NPT30Silber-001.dxf
- DOK_PRD_EL_51029-Adapter-G-30-NPT-30-Silber-2012.pdf
- DOK_PRD_DB_51026-AdapterG10-NPT10Silber.pdf
- ZEI_PRD_3D_51029-AdapterG30-NPT30Silber-001.dwg
