Orb Nozzle Stainless Steel - Vulcan INT
View other products in the family
","en-GB":"Orb Nozzle Vulcan 1 is a high-quality stainless steel nozzle for ground installation that perfectly fits OASE LED spotlights and is the first choice for premium design and durability. The integrated water softener guarantees a fantastically clear and precise water pattern for an exhilarating single-tier vulcan effect. The Orb Nozzle fits perfectly on the nozzle connection of the OASE SplashCore water switch, to which it is simply fastened with three screws. The OASE-exclusive SplashKit multitool, which is available separately, helps to install and align the nozzle: This tool makes it possible to move the Orb Nozzle by 5° in any direction in order to produce a vertical water jet, for example, even on a slope. Replacing the nozzle inserts is very quick and easy too: The nozzle can be accessed directly from above without having to remove the entire effect unit. Four additional Orb Nozzles with different effects are available in the stainless steel version: Comet 10, Comet 12, Cluster and Calyx provide fascinating and varied shows.
","nl-NL":"Orb Nozzle Vulcan 1 is a high-quality stainless steel nozzle for ground installation that perfectly fits OASE LED spotlights and is the first choice for premium design and durability. The integrated water softener guarantees a fantastically clear and precise water pattern for an exhilarating single-tier vulcan effect. The Orb Nozzle fits perfectly on the nozzle connection of the OASE SplashCore water switch, to which it is simply fastened with three screws. The OASE-exclusive SplashKit multitool, which is available separately, helps to install and align the nozzle: This tool makes it possible to move the Orb Nozzle by 5° in any direction in order to produce a vertical water jet, for example, even on a slope. Replacing the nozzle inserts is very quick and easy too: The nozzle can be accessed directly from above without having to remove the entire effect unit. Four additional Orb Nozzles with different effects are available in the stainless steel version: Comet 10, Comet 12, Cluster and Calyx provide fascinating and varied shows.
","cs-CZ":"Orb Nozzle Vulcan 1 is a high-quality stainless steel nozzle for ground installation that perfectly fits OASE LED spotlights and is the first choice for premium design and durability. The integrated water softener guarantees a fantastically clear and precise water pattern for an exhilarating single-tier vulcan effect. The Orb Nozzle fits perfectly on the nozzle connection of the OASE SplashCore water switch, to which it is simply fastened with three screws. The OASE-exclusive SplashKit multitool, which is available separately, helps to install and align the nozzle: This tool makes it possible to move the Orb Nozzle by 5° in any direction in order to produce a vertical water jet, for example, even on a slope. Replacing the nozzle inserts is very quick and easy too: The nozzle can be accessed directly from above without having to remove the entire effect unit. Four additional Orb Nozzles with different effects are available in the stainless steel version: Comet 10, Comet 12, Cluster and Calyx provide fascinating and varied shows.
","it-IT":"Orb Nozzle Vulcan 1 is a high-quality stainless steel nozzle for ground installation that perfectly fits OASE LED spotlights and is the first choice for premium design and durability. The integrated water softener guarantees a fantastically clear and precise water pattern for an exhilarating single-tier vulcan effect. The Orb Nozzle fits perfectly on the nozzle connection of the OASE SplashCore water switch, to which it is simply fastened with three screws. The OASE-exclusive SplashKit multitool, which is available separately, helps to install and align the nozzle: This tool makes it possible to move the Orb Nozzle by 5° in any direction in order to produce a vertical water jet, for example, even on a slope. Replacing the nozzle inserts is very quick and easy too: The nozzle can be accessed directly from above without having to remove the entire effect unit. Four additional Orb Nozzles with different effects are available in the stainless steel version: Comet 10, Comet 12, Cluster and Calyx provide fascinating and varied shows.
","de-DE":"Die hochwertige Edelstahldüse – Orb Nozzle Vulkan 1 – für den Bodeneinbau, passgenau für OASE LED-Scheinwerfer, ist die erste Wahl in puncto Premiumdesign und Langlebigkeit. Der integrierte Wasserberuhiger garantiert ein traumhaft klares und präzises Wasserbild – für einen begeisternden einstufigen Vulkan-Effekt. Die Orb Nozzle passt perfekt auf den Düsenanschluss des Wasserschalters OASE SplashCore, an dem sie einfach mit drei Schrauben befestigt wird. Bei Montage und Ausrichtung der Düse hilft das OASE-exklusive, separat erhältliche SplashKit Multitool: Die Orb Nozzle kann damit in jede Richtung um 5° verstellt werden, um z. B. auch im Gefälle einen senkrechten Wasserstrahl zu erzeugen. Auch der Austausch der Düseneinsätze geht so schnell und einfach: Die Düse ist direkt von oben zugänglich, ohne die gesamte Effekteinheit ausbauen zu müssen. In der Edelstahlausführung sind vier weitere Orb Nozzles mit unterschiedlichen Effekten erhältlich: Komet 10, Komet 12, Cluster und Kelch sorgen für faszinierende und abwechslungsreiche Shows.
","pl-PL":"Orb Nozzle Vulcan 1 is a high-quality stainless steel nozzle for ground installation that perfectly fits OASE LED spotlights and is the first choice for premium design and durability. The integrated water softener guarantees a fantastically clear and precise water pattern for an exhilarating single-tier vulcan effect. The Orb Nozzle fits perfectly on the nozzle connection of the OASE SplashCore water switch, to which it is simply fastened with three screws. The OASE-exclusive SplashKit multitool, which is available separately, helps to install and align the nozzle: This tool makes it possible to move the Orb Nozzle by 5° in any direction in order to produce a vertical water jet, for example, even on a slope. Replacing the nozzle inserts is very quick and easy too: The nozzle can be accessed directly from above without having to remove the entire effect unit. Four additional Orb Nozzles with different effects are available in the stainless steel version: Comet 10, Comet 12, Cluster and Calyx provide fascinating and varied shows.
","hu-HU":"Orb Nozzle Vulcan 1 is a high-quality stainless steel nozzle for ground installation that perfectly fits OASE LED spotlights and is the first choice for premium design and durability. The integrated water softener guarantees a fantastically clear and precise water pattern for an exhilarating single-tier vulcan effect. The Orb Nozzle fits perfectly on the nozzle connection of the OASE SplashCore water switch, to which it is simply fastened with three screws. The OASE-exclusive SplashKit multitool, which is available separately, helps to install and align the nozzle: This tool makes it possible to move the Orb Nozzle by 5° in any direction in order to produce a vertical water jet, for example, even on a slope. Replacing the nozzle inserts is very quick and easy too: The nozzle can be accessed directly from above without having to remove the entire effect unit. Four additional Orb Nozzles with different effects are available in the stainless steel version: Comet 10, Comet 12, Cluster and Calyx provide fascinating and varied shows.
"}
Détails des caractéristiques
5° réglable dans toutes les directions - par exemple pour un faisceau vertical, même sur une pente
Calmeur d’eau intégré pour une image d’eau claire
Parfait dans le système du SplashKit et avec l’interrupteur d’eau SplashCore
Buse pour installation au sol, presque entièrement intégrée dans le sol
Alignement des inserts de bille ainsi que leur nettoyage et remplacement facilement et rapidement avec l’outil multifonction SplashKit disponible séparément
Inclus dans la livraison de la buse orb (77879)
version robuste en plastique de couleur anthracite avec six inserts d’effet
Vendu séparément
versions en acier inoxydable de haute qualité en cinq versions à effet unique
Éclairage parfait grâce au montage dans des projecteurs LED OASE - soit SplashKit LED XL RGrBW, soit ProfiPlane LED XL RGB Spot ou ProfiRing LED XL RGB Spot
Divers effets possibles
Comète 10, Comète 12, Cluster, Vulcain à 1 étage ou à 2 étapes ainsi que Calice
Spécifications
Specification breakdown
- Dimensions (Ø × h)
- 69 × 105
- mm
- Matériel
- Plastique/acier inoxydable 1.4301 (AISI 304)
- Poids net
- 0.502
- kg
