VarioDrop /01
SKU: 92485
Key features
- Exceptional water effect: Droplets appear to float in the air
- Fully submerged technology enhances visual weightlessness
- Perfectly matched combination of 24 V solenoid valve (12 V on request) with water supply line and Comet fountain attachment
Weightlessness in droplet form – the VarioDrop creates this extraordinary effect. Whether fresh or pool water, the 0.9 m-high fountain creates fascinating moments of weightlessness before the voluminous, floating droplets descend back into the pool. This is ensured by the perfectly matched combination of a 24 V solenoid valve with water supply line and the Comet fountain attachment – for highly precise, dynamic and rhythmic water features. The technology is completely hidden below water and supports this weightless effect.
Feature Details
Particularly secure, patented ProNect connection of the Underwater Switch
Perfectly matched combination of 24 V solenoid valve (12 V on request) with water supply line and comet fountain attachment
For fascinating light installations with bracket for spotlights ProfiLux LED S
Extraordinary water effect
Drops seem to float in the air
Technology completely hidden under water enhances visual weightlessness
Best performance, as a sludge trap prevents the nozzle from getting dirty
Slide 1 of 3
1 of 3
Specifications
Specification breakdown
- Dimensions (L × W × H)
- 215 × 80 × 130
- mm
- Power consumption
- 5
- W
- Rated voltage
- 24 V / DC
- Protection class
- IP68
- Power connection type
- 24 V DC plug
- Power cable length
- 4.00
- m
- Water level min.
- 200
- mm
- Waterlevel max.
- 215
- mm
- Pressure-side connection
- G ½
- Material
- Stainless steel 1.4301 (AISI 304) / Plastic
- Net weight
- 1.95
- kg
Downloads
- 3D drawing
- 2D drawing
- Product instructions
- 2D drawing
- Product data sheet
