ProfiRing LED L RGB Spot /DMX/02
SKU: 72708
View other products in the family
Feature Details
DMX/RDM-capable with the Underwater LED-Driver Compact/DMX/02, dimmable, perfect for strobe effects
Galvanic isolation between DMX and 24 V DC
Powerful, robust RGB LED spotlight for wet and dry installation with homogeneous coloured illumination by uniformly calibrated LEDs
Level surface by stepped glass prevents dirt deposits
Waterproof according to IP68 up to 4 m water depth
1 m cable length with patented waterproof OASE ProNect connector
Temperature-controlled, high-quality brand LEDs with a lifespan of up to 100,000 hours*
Slide 1 of 2
1 of 2
Slide 1 of 6
1 of 6
Specifications
Specification breakdown
- Certificate
- Dekra US + C
- Number of DMX channels
- 5
- Units
- DMX Channel 1
- red
- DMX Channel 2
- green
- DMX Channel 3
- blue
- DMX Channel 4
- strobe
- DMX Channel 5
- dimmable
- Luminous flux with all on
- 837
- lm
- Luminous flux red
- 240
- lm
- Luminous flux green
- 460
- lm
- Luminous flux blue
- 137
- lm
- Beam angle
- 16 Degrees (± 2)
- Stroboscope effect
- 0-25 Hz
- Weighted energy consumption
- 24
- kWh/1000h
- Rated voltage
- 24 V / DC
- Power consumption
- 21
- W
- Rated current
- 0.95
- A
- Dim frequency
- 2800
- Hz
- Power connection type
- Hybrid plug
- Power cable length
- 1.00
- m
- Protection class
- IP68; 4 m
- Dimensions (Ø × H)
- 125 × 30
- mm
- Material
- Stainless steel 1.4404 (AISI 316L)
- Net weight
- 1.2
- kg
Downloads
- ZEI_PRD_3D_72708-ProfiRing-LED-L-RGB-Spot-DMX-02-001.dwg
- ZEI_PRD_AC_72708-ProfiRing-LED-L-RGB-Spot-DMX-02-001.dxf
- ZEI_PRD_AC_72708-ProfiRing-LED-L-RGB-Spot-DMX-02-System-001.dxf
- ZEI_PRD_LDT_72708-ProfiRing-LED-L-RGB-Spot-DMX-02.zip
- DOK_PRD_EL_72708-ProfiRing-LED-L-RGB-Spot-DMX-02-001.pdf
- DOK_PRD_DB_72708-ProfiRing-LED-L-RGB-Spot-DMX-02.pdf
- DOK_PRD_LV_72708-ProfiRing-LED-L-RGB-Spot-DMX-02.pdf
- ZEI_PRD_AC_72708-ProfiRing-LED-L-RGB-Spot-DMX-02-Einbauzeichnung-001.dxf
- DOK_PRD_GA_91474-GA-LED-FT-RGBW-steuerbar-01.pdf
