Detaily vlastností
Safety low voltage 24 V DC
Controllable via DMX/RDM
Swinging water effect at fountain heights of up to 8 m
Single-axis drive with a swivel range of 90°
Exciting effects in combination with nozzles such as Comet or Cluster Eco
Robust stainless steel design
For fresh and pool water, with a minimum water height of 300 mm and a maximum water height of 390 mm
Energy-efficient motor, 24 V DC
Slide 1 of 5
1 of 5
Specifikace
Specification breakdown
- Number of DMX channels
- 4
- Units
- DMX Channel 1 x axe
- Position
- DMX Channel 2 x axe
- Fine
- DMX Channel 3 x axe
- Speed
- DMX Channel 4 x axe
- Function
- Max. operating pressure
- 1.3
- bar
- Water level min.
- 300
- mm
- Waterlevel max.
- 390
- mm
- Swing Range - Factory
- 90
- °
- Swing Speed max.
- 72.00
- °/sec.
- Connection nozzles
- G 1 ½ (internal thread)
- Pressure-side connection
- G 2
- Power consumption
- 22
- W
- Rated voltage
- 24 V / DC
- Rated current
- 0.9
- A
- Power connection type
- Power-Box 24 V DC /01
- DMX-RDM connection type
- DMX-Box /01
- Protection class
- IP68
- Dimensions (L × W × H)
- 577 × 432 × 386
- mm
- Material
- Stainless steel 1.4301 (AISI 304)
- Net weight
- 22
- kg
Stažení
- ZEI_PRD_3D_72888-Swivel-DMX-02-001.dwg
- ZEI_PRD_AC_72888-Swivel-DMX-02-001.dxf
- ZEI_PRD_AC_72888-Swivel-DMX-02-LED-Modul-Cluster-001.dxf
- ZEI_PRD_AC_72888-Swivel-DMX-02-LED-Modul-Komet-001.dxf
- DOK_PRD_DB_72888-Swivel-DMX-02-001.pdf
- DOK_PRD_EL_72888-Swivel-DMX-02-001.pdf
- DOK_PRD_LV_72888-Swivel-DMX-02-001.pdf
- DOK_PRD_GA_73037-GA-Swivel-S-DMX-02-01.pdf
