Fan Jet 30 - 11 E INT
SKU: 46983
View other products in the family
Klíčové vlastnosti
- Fan-shaped gush of water
- Modern stainless steel look
- Stainless steel nozzle
Detaily vlastností
The Model 30 - 11 E creates water walls of up to 9 m high and 27.6 m wide
Perfect as a projection surface for projector and laser shows and for use with the effect unit Multi Directional Drive XL 3D /DMX/02 and Multi Directional Drive L 3D /DMX/02
Aesthetic, fan-shaped water veils
Depending on the installation direction of the nozzles, different water images are created, e.g. water veils or water gushes
A throttle device is required to adjust the water pattern
Modern, high-quality stainless steel look
Specifikace
Specification breakdown
- Dimensions (L × W × H)
- 267 × 98 × 220
- mm
- Water film thickness
- 11.0
- mm
- Material
- Stainless steel 1.4571 (AISI 316Ti)
- Net weight
- 4.054
- kg
Stažení
- DOK_PRD_DB_46983-Fan-Jet-30-11-E.pdf
- ZEI_PRD_3D_46983-Faecherduese-30-11E-001.dwg
- ZEI_PRD_AC_46983-Faecherduese-30-11E-001.dxf
